Adhesive Vent | Outdoor Electronics: Security Camera

IPRO Home Application Outdoor Electronics VentsSecurity Camera Adhesive Vent

Adhesive Vent

Temperature changes in external environment and during equipment operation may lead to pressure differences. IPRO adhesive vents offer effective waterproof and dust-proof protection, and can equalize pressure, prevent lens from cracking under pressure, and extend the service life of security cameras

Technical Data

    • WEP: 20-150kPa
    • Air Flow: 2000-25000ml/min cm2@7kPa
    • IP Rating: IP64, IP65, IP66, IP67, IP68
    • Operating Temperature: -40℃-+85℃
get enquiry

Contact to IPRO

Welcome to contact IPRO to get more information about products and services. Simply send us a message through our contact form and the responsible contact person will get in touch with you as soon as possible.

IPRO may contact me to inform me of products, programs, services, and promotions. I understand that I can opt out at any time.
For additional information related to our privacy practices, review our Privacy Policy

Product Application : Adhesive Vent


Outdoor smart security camera is constantly exposed to scorching sunlight. Temperature change of the external environment can easily lead to a large amount of heat being accumulated inside the casing, resulting in pressure differences, lens rupture, sealing structure failure and equipment damage. If the device is completely sealed, then internal water vapor cannot disperse, which will form condensations and affect lens performance. Therefore, the cavity is usually not completely sealed but leaving channels connecting to the external environment for pressure equalization. However, this leaves the device vulnerable to dust and rain intrusions, which may result in electronic components damage and short circuits, posing safety threats. IPRO adhesive vents offer effective waterproof and dust-proof solutions, and can quickly equalize pressure, as well as reduce lens fogging caused by vapor condensation. What is more, it also prevents sealing structures failure, casing deformation and lens rupture, thus ensuring the long-term reliability of smart security cameras.

Key Features
  • High level of strong water spray protection
  • High air permeability
  • Stable air permeability
  • Customized sizes available
  • Excellent long-term reliability
