Aluminum Foil Induction Liner | Packaging: Agrochemicals

Using ultrasonic or thermal sealing method to weld aluminum foil liners together with breathable membranes, you get aluminum foil induction liners, which has the advantages of simple design, easy installation, easy welding and sealing, as well as excellent chemical and surfactant resistance capabilities, plus good air permeability. With this liner, clients can choose whether or not to punch holes in the bottle caps during application process, this is because the gaps between the outer surface of the aluminum foil induction liners and the bottle caps allow the gas to pass through the vent and the threaded holes before being discharged. However, the gas will be discharged faster with holes.



Aluminum foil induction liners are suitable for small volume packaging (less than 5L), so it is widely used in the packaging of pesticides and liquid fertilizers. It has various sizes and models. Customers can choose according to casing materials and their specific needs. If the casing is made of PE, customers can choose aluminum foil induction liners with PE membrane attached. If it is PET, then with PET membrane attached.



Product Technical Specifications:

Characteristics	AILB-4603-X-8.25	AILB-4603-X-10.25	AILB-4603-X-12.7
Oil Rating	7	7	7
Typical Air Flow	1000ml/min@7kPa	1500ml/min@7kPa	2400ml/min@7kPa
WEP (60s)	＞80kPa	＞80kPa	＞80kPa
Reference Thickness	1mm	1mm	1mm
Membrane Type	ePTFE	ePTFE	ePTFE
Membrane Characteristics	Oleophobic	Oleophobic	Oleophobic
Membrane Color	White	White	White

• No Punching of Holes Required
• Pressure Equalization
• Long Service Life
• Various Sizes Available
• Good Product Stability
• Easy to Seal

Suggestions for Storage and Transportation: The liner material is sensitive to heat. A high-temperature environment will damage the liner and affect its performance. Therefore, it can only withstand short-term storage at 0-40℃. If it needs to be used for a long time, we recommend liners and caps with liners to be placed indoor with temperature between 5-35℃ and humidity between 30%-75%. Otherwise, liners will curl and deform, and the aluminum foil will get separated from the paperboard, making it unusable.



Handling Method: If the storage site does not meet the above requirements, please place these liners in an environment where the temperature is between 15℃-30℃ for 48 hours before use, and then decide whether to actually use them based on liner conditions.
